Enhanced Night Vision Viewer 12um Thermal Imaging Extra Large Exit Pupil Diameter 15mm
Product Details:
| Place of Origin: | China |
| Brand Name: | HEWEI |
| Certification: | Yes |
| Model Number: | HW-JY-F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 piece |
|---|---|
| Packaging Details: | Carton package |
| Delivery Time: | 10-45 working days |
| Supply Ability: | 100 per month |
|
Detail Information |
|||
| Visual Amplification: | 1× | Exit Pupil Diameter: | 15mm |
|---|---|---|---|
| Exit Pupil Distance: | 25mm | Diopter: | -3.5~+2.5 |
| Display Mode: | Black-hot/ White-hot/ Orange-hot, Outline, Target Highlight, Breathing Alert | Compass Indication: | Azimuth/ Pitch Angle/ Inclination Angle |
| Battery Life（I² Only): | ≥60h | Battery Life (All Functions): | ≥8h |
| Weight: | ≤360g (Without Battery Pack) | Operating Temperature: | -40℃ ~ +60℃ |
| High Light: | enhanced night vision viewer,12um night vision viewer,15mm dia night vision viewer |
||
Product Description
Enhanced Night Vision Goggle
HW-JY-F Enhanced Night Vision Goggle combines I² and thermal imaging technologies to make up for the shortcomings of the former in detecting targets, suitable for a wider range of applications. With corresponding sighting tools, the field of vision and the division of the sighting tool can be precisely matched to the image of HW-JY-F, so as to realize the fast capture and concealed shooting of the target.
- Technical Parameters
| Product Specifications | |
| Visual Amplification | 1× |
| Exit Pupil Diameter | 15mm |
| Exit Pupil Distance | 25mm |
| Diopter | -3.5~+2.5 |
| Display Mode | Black-hot/ White-hot/ Orange-hot, Outline, Target highlight, Breathing alert |
| Compass indication | Azimuth/ Pitch angle/ Inclination angle |
| Battery Life(I² Only) | ≥60h |
|
Battery Life (All Functions) |
≥8h |
| Weight | ≤360g (Without Battery Pack) |
| Operating Temperature | -40℃ ~ +60℃ |
| I² Specifications | |
| I² Focal Length | 25mm |
| Focal Length Range | 0.25m ~ +∞ |
| I² FOV | 40° |
| Gain Adjustment | Support |
| Infrared Specifications | |
| Detector | 12μm 640×512 |
| IR Focal Length | 16mm |
| Infrared FOV | 26.9°×20.9° |
| Gain Adjustment | Support |
| Contrast Control | Support |
| Operating Distance | ||
|
Human Target 1.7m×0.5m |
Identification | 200m |
| Recognition | 400m | |
| Detection | 1500m | |
|
Vehicle Target 2.3m×2.3m |
Identification | 500m |
| Recognition | 1000m | |
| Detection | 3000m | |
