Product Details:
Payment & Shipping Terms:
|
Technology: | Compton Backscatter Scanning(CBS) | Source: | X-ray Source |
---|---|---|---|
Detector Array: | NaI (Tl) + PMT | Each Effective Scanning Time: | ~3 Sec |
Display: | TFT LCD With Touch-screen | Identify Substance: | 8 Kinds Of Liquids |
Minimum Amount Of Detectable Liquid: | ~80ml | Alarm: | Audio And Light |
Portable Explosive Detector For Liquid Contraband Detection
Introduction
Liquid Contraband Detector is the only unique one device in the world which adopts up-to-date Compton
Backscatter Scanning (CBS) technology, the detector is used to inspect the carry-on containers whether exist
flammable and explosive, corrosive liquids in the field. It can identify the unknown liquids in sealed containers
quickly, safely and accurately without opening the containers. No limits from the package material.
Special Features
·High intelligent and quick identification
·Ease operation and safe use
·High sensitivity and accuracy
·Complete function, stable and reliable
·No limits from the package material (ceramic, plastic, glass, light metal etc), containers’ material, liquid colors,
types of liquid substances, liquid amount inside the sealed containers.
Functions
It can precisely and automatically identify 8 kinds of liquids:
Liquid explosives (such as TATP and nitroglycerin);
Flammable liquids (such as gasoline, alcohol, diesel and kerosene),
Corrosive liquids (such as various acids and alkali),
Organic solvents and volatilize liquids (such as acetone and ether),
Water (such as pure water, mineral water and sprite);
Fruit juice;
Dairy
Alcohol (such as white wine and beer), etc.
Applications
· Passengers checks in airports and public transportation
· Customs and ports
· Prisons
· Security checkpoints
· Sports and entertainment places
Specifications
Item |
Description |
Technology |
Compton Backscatter Scanning(CBS) |
Source |
X-ray Source |
Detector Array |
NaI (Tl) + PMT |
Size |
48×42×32cm |
Weight |
Less than 40kg |
Each Effective Scanning Time |
~3 sec |
Display |
TFT LCD with touch-screen |
Identify Substance |
8 kinds of liquids |
Radiation Safety (with shield) |
≤ 1µSv/hr |
Minimum Amount of Detectable Liquid |
~80ml |
Indicator |
None |
Alarm |
Audio and Light |
Power Supply |
110/220V AC |
