Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area

Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area
Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area

Large Image :  Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area

Product Details:
Place of Origin: Made-in-China
Brand Name: HEWEI
Certification: YES
Model Number: HWXRY-03
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 15500~37000 per set FOB Shenzhen
Packaging Details: Carton package, wooden package
Delivery Time: 20 working days
Payment Terms: T/T
Supply Ability: 30 sets per month
Detailed Product Description
Name: 433mm X 354mm (Standard) Detection Area, Light Weight, Handheld Xray Baggage Inspection System Detector Thickness: 15mm
Pixel Pitch: 154 μm Limiting Resolution: 3.3 Lp/mm
Weight: Weight Operating Temperature: -10℃+55℃
High Light:

154um handheld x ray scanner

,

eod handheld x ray scanner

,

154um handheld portable x ray machine

433mm x 354mm (Standard) detection area, Light weight, handheld xray baggage inspection system

Handheld XRAY scanner system



Description:

This device is a light weight, portable, battery powered x-ray scanning system designed in co-operation with the first responder and EOD teams to meet the need of the field operative. It is light weight and comes with user friendly software that helps operators in understanding the functions and operations in a less time.



Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area 0













































Applied Scene:

Applied Scene:



Widespread use of explosives presents immense growing challenges and threats to civilians, law enforcement forces, military and police bomb squads and EOD teams worldwide. The key objective of Bomb Disposal Operators is to accomplish their task as safely as possible. For that reason, EOD equipment, and specifically portable x-ray scanner systems play a crucial role in meeting this objective -providing real time, high quality images of suspect objects, while ensuring the safety of all parties involved.



Counter Surveillance



The portable X-ray scanner system plays a crucial role in inspecting everyday objects - such as electronic devices, furniture, walls (concrete, drywall) and even inspecting an entire hotel room. When guarding a public figure, or an embassy, these items as well as innocent looking gifts or mobile phones must be inspected for the slightest alteration in their electronic components which may imply it is being used as a listening device.



Specification:

A Technical Specification of the imaging plate
1 Detector Type Amorphous Silicon with TFT
2 Detector Area 433mm x 354mm (Standard)
433mm x 433mm (Optional)
3 Detector Thickness 15mm
4 Pixel pitch 154 μm
5 Pixel array 2816X2304
6 Dynamic Range 16 bits
7 Limiting Resolution 3.3 lp/mm
8 Image Acquisition Time 4-5s
9 Weight 6.4 kg with battery
10 Power supply 220V AC/50Hz
11 Communication Wired: 50 meters fiber on a roller, TCP/IP Ethernet
Wireless: 5G Wi-Fi , no less than 70m
12 Operating Temperature -10℃+55℃
13 Humidity 0% to 95% non-condensing
Technical Specification-x-ray Generator
1 Operating Mode Pulse, it launches 4000 pulses each time when charged fully
2 Best Detecting Distance 0.7m
3 Working hours More than 5 hours
Battery Rechargeable Li Ion battery
1 spare battery
4 Voltage 150kV, Pulsed (safety to operator)
5 Penetration 50mm Aluminium Plate
6 Weight 5 Kg with battery
7 Power supply 220V AC/50Hz
8 Safety Key Switch, Audible & Visible alarm signs
Technical Specification – Imaging Station (PC)
1 Type Laptop computer
2 Processor The Intel Core i5 processor
3 Display 13 or 14” Full High Definition LED Display
4 Memory 8GB
5 Hard Drive no less than 500GB
6 Operating system English MS Windows 10
7 Software

Automatic Optimization, Invert, Revert, Pseudo color image, Rotate, Flip Horizontal, Flip Vertical, Zoom, Deep Focus, Polygon

On screen measurement, Merge, Save, 3D image



Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area 1



Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area 2



Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area 3



Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area 4



Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area 5



Lightweight Handheld Baggage 154um Handheld X Ray Scanner 433mm X 354mm Standard Detection Area 6
