1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof
1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

Large Image :  1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

Product Details:
Place of Origin: China
Brand Name: HEWEI
Certification: YES
Model Number: UMD-III
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1600~2500
Packaging Details: carton package, wooden package.
Delivery Time: 15 ~30 working days
Payment Terms: T/T
Supply Ability: 100 sets per month
Detailed Product Description
Name: 1090mm~1360mm Detecting Pole Length Mine Detector Weight: 3 Kg
Transport Weight: 12.3 Kg The Detecting Pole Length: 1090mm~1360mm
Battery: LR20 Manganese Alkali Dry Cell Battery Life: At Maximum Sensitivity - 12 Hours At Medium And Low Sensitivity - 18 Hours Low Voltage Alarming By Sound And Light
Detection Sensitivity: Detection Sensitivity Operating Humidity: Fully Enclosed And Be Able To Operate 2 M Under Water.
High Light:

1360mm Detecting Pole Length Mine Detector

,

1090mm Detecting Pole Length Mine Detector

,

HEWEI Mine Detector Waterproof

1090mm~1360mm detecting pole length, water-prooof Mine detector



Mine detector



Description

UMD-III mine detector is a widely used hand-held (single-soldier operating) mine detector. It adopts high frequency pulse induction technology and it is highly sensitive, especially suitable for detecting minor metal mines. The operation is simple, so the operators can use the device only after a short training.



Features

  • Waterproof, which can be detected under water.
  • Being controlled by a microprocessor with accurate timing, fast conversion and strong signal processing capability.
  • Super sensitivity to identify very small metal objects.

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 0



Technical Parameters



Weight 3kg
Transport weight 12.3 kg
The detecting pole length 1090mm~1360mm
Battery LR20 Manganese alkali dry cell
Battery life

At maximum sensitivity - 12 hours

At medium and low sensitivity - 18 hours

Low voltage alarming by sound and light

Detection sensitivity 0.05gr Stainless steel at 75mm distance from the probe
Operating humidity Fully enclosed and be able to operate 2 m under water.
Operating temperature -25°C~70°C
Storage temperature -25°C~70°C
The detecting coil The longest detecting pole is 1120mm, the shortest is 700mm, and weight 1100g. Glass resin telescopic rod, the surface is coated to protect the environment.The diameter of detecting coil is 300mm, black ABS material, surface is treated with EMC, and a hybrid RX coil is used to improve the signal/noise ratio.





1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 1



1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 2



1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 3



1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 4



1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 5



1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 6



1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof 7
